| CONSTRUCTION RCD Status: • Our understanding is that the vessel is CE certified for category A – OCEAN for up to 11 persons. Hull Construction: • GRP moulded hull • GRP form internal structural members, fully laminated to hull • Plywood bulkheads laminated to hull and deck • Original white gelcoat finish to topsides with blue sheerband • Stainless steel framed portholes • Full osmosis treatment completed in 2021 • Underwater hull finished with Copper Coat applied following osmosis treatment in 2021 • Boat slipped in August 2024 for anode replacement and antifouling of bow and stern thurster tunnels. Deck & Superstructure Construction: • GRP moulded deck, incorporating coachroof and deck house structure • GRP moulded deckhouse roof incorporating self-draining flybridge • GRP moulded aft deck sun canopy • White gelcoat finish with moulded non-slip textured panels on coachroof top • Stainless steel framed deck hatches and windows • Stainless steel frames doors aft and to starboard • Laid teak decking to finish foredeck, side deck, aft deck and bathing platform MACHINERY Port Engine & Gearbox: • Yanmar 6CXM-GTE2 • 440hp @ 2,800RPM • 6 Cylinder, turbo charged, indirectly cooled • Gauges for RPM, Eng Oil Pressure, Temperature, Voltage, Gearbox Oil Pressure • Kobelt single lever controls at both helm stations • HMI exhaust alert system • Racor primary fuel filter unit Starboard Engine & Gearbox: • Yanmar 6CXM-GTE2 • 440hp @ 2,800RPM • 6 Cylinder, turbo charged, indirectly cooled • Gauges for RPM, Eng Oil Pressure, Temperature, Voltage, Gearbox Oil Pressure • Kobelt single lever controls at both helm stations • HMI exhaust alert system • Racor primary fuel filter unit Maintenance & Performance: • Engine last serviced spring 2025 • Generator last serviced spring 2025 • Engine anodes replaced August 2024 • Engine Hours Port – 1337 • Engine Hours Starboard – 1340 • Cruising speed 14kts • Max Speed 20kts Propulsion & Steering: • Stainlesss steel prop shafts • Waterfed compression gland type stern glands • Bronze propellors • Dual station hydraulic steering system Bow Thruster: • SidePower tunnel mounted thruster 16hp • Joystick type controller at both helm stations • Remote control fob allowing control of both bow and stern thrusters Stern Thurster: • SidePower, electric transom mounted stern thruster • Joystick type controller on flybridge • Remote control fob allowing control of both bow and stern thrusters Trim Tabs: • Bennett trim tab system • Electro hydraulic system • Rocker switch type controls at both helm stations • Position indicators at both helm stations Autopilot: • Simrad Robertson system • Simrad AP22 control heads at both helm stations • Hydraulic drive system ELECTRICAL SYSTEMS Voltage systems: • 24VDC onboard power system • 220vAC supplied via shore power or generator Battery Banks: • Domestic – 2x 12VDC, 200Ah, Yuasa lead acid • Engine Battery – 2x 12VDC, 200Ah, Yuasa lead acid • Generator Battery – 1x 12VDC, 60Ah, Varta 24VDC Charger: • Dolphin Power 1 First battery charger • 220vAC – 24DC, 80amp Generator: • Onan MKAD-4962013 220vAC marine diesel generator • 13.5kW output • Hours 926.3 Shore Power System: • Extension lead to connect to 220vAC shore supply • Dual 32amp and 16 amp connection points • Hardwired RCD-protected system. • 3 pin continental type sockets with UK adapters, battery charger, immersion heater Other Electrical: • Searchlight – Guest combined search and flood light unit. 360 degree rotation. Control panels at both helm stations • Windscreen Wipers – Pantograph arms, multi-speed • Horn PLUMBING Fresh Water: • Pressurised hot and cold water systems • Mixer tap in galley • Hot and cold taps in forward heads with dedicated shower fitting • Hot and cold taps in aft cabin • Hot water provided from calorifier, heated by engine cooling water or 230VAC immersion heater Black Water: • Single holding tank for both heads • Deck pump-out or macerator discharge Bilge Pumps: • Manual Bilge Pump • Electric Bilge Pump – x3 with manual and auto operation, indicator lights at both helm stations TANKAGE Fuel: • Dual diesel tanks • 302gallons each • Approximate total capacity 2270ltrs Fresh Water: • Single fresh water tank • Approximate capacity 909ltrs Holding Tank: • Single holding tank • Connected to both forward and aft heads • Approximate Capacity 100ltrs Calorifier: • Single insulated tank • Approximate capacity 50ltrs • Heated by engine cooling water or 230VAC immersion heater Tank Monitoring: • Independent gauges for each fuel tank • Tank Watch 4 level indicator system for water tank – Not operational currently NAVIGATION & COMMUNICATION EQUIPMENT On Deck: • Plotter/Radar – Raymarine C120W with UK/Ireland cartorgraphy • Repeater – Simrad IS15 showing depth and log information • Magnetic compass Internal Helm Station: • Plotter/Radar – Raymarine C120W with UK/Ireland cartorgraphy • Repeater – Simrad IS15 showing depth and log information • Magnetic Compass – Plastimo 135 • Clock • Barometer Communications Equipment: • DSC VHF – Ray 240e black box system with commandmic stations at each helm • Handheld VHF – Standard Horizon HX300 • NASA Weatherman DOMESTIC EQUIPMENT Galley: • HOB – SMEG 230VAC, 4 plate • Oven – SMEG 230VAC, fan oven with grill • Combi Microwave/Grill – SMEG 230VAC • Fridge/Freeze – Coolmatic free standing fridge freezer, front loading • Drinks Fridge – Euro Engle Front loading fridge in saloon with icebox • Toaster – Russel Hobbs, 230VAC • Kettle – Breville, 230VAC • Mixer tap with separate pull out spray head • Double stainless steel sinks • Corian worktop Laundry: • Washer/Dryer – Aquarius 1100, 230VAC Forward Heads: • Jack’n’Jill with forward cabin • Toilet – Electric flush marine toilet • Marble countertop • Wash hand basin with mixer tap • Shower cubicle with bulkhead-mounted shower head Aft Heads: • Toilet – Electric flush marine toilet • Marble countertop • Wash hand basin with mixer tap • Dedicated shower/bath with mixer tap and shower head Air Conditioning / Heating: • HFL Klima system, 230AC • Dual compressor HFL KCC25KHZ, 25,000BTU • Reverse cycle to provide heat Lighting: • Overhead downlighters with LED bulbs throughout • Lamps in saloon • Reading lights in cabins • Engine space lighting Entertainment: • Stereo – JVC CD/Radio head unit • TV – Sony Bravia ACCOMMODATION Accommodation Finish: • Joinery work below decks of teak veneered plywood with solid teak trims • Cherry and holly soleboards throughout interior • All joinery work finished in a satin varnish • Marble counters in heads • Corian counters in galley • Vinyl covered headlining panels throughout interior • Fitted carpets in the dinette, forward cabin, aft cabin and twin cabin • Soft cream leather upholstery in wheelhouse and dinette • Curtains of blinds for all portlights and portholes. Description of Accommodation from Forward: Forward Cabin: • Double island berth forward, centrally • Standing room aft of bunk spanning full width of cabin with access to bunk on port and starboard sides • Three storage drawers beneath bunk at aft end • Counter top outboard of bunk to port and starboard and wrapping around forward end of bunk, vanity lockers beneath counter tops • Opening deck hatch above bunk centrally • Full-height storage lockers outboard to port and starboard with drawers beneath • En-suite access to forward heads aft to starboard. Forward Heads: • Accessed from starboard side of passageway forward • Jack’n’Jill en-suite access from forward cabin • Electric flush marine toilet outboard centrally • Marble topped countertop forward with inset wash hand basin and mixer tap • Vanity lockers above wash hand basin outboad and over head above toilet • Shower stall aft with fixed door, marble topped seat outboard, shower head and fittings mounted on bulkhead aft Port Cabin: • Accessed to port side of passageway forward • Twin bunk cabin with thwartship bunks located forward and aft • Standing room between bunks centrally • Dresser unit outboard of standing room with counter top, storage drawers beneath and locker above with mirror mounted on door • Four storage drawers beneath each bunk • Two storage lockers above forward bunk, inboard Helm Station: • Located to starboard side, forward of deck saloon • Double, forward-facing bench seat with sliding door to access starboard side deck outboard with optional foot rest • Helm forward • Engine controls, dashboard , plotter and other controls all mounted forward of helm • Navigation area to port side with large chart table working area, lifting to provide storage beneath, counter top outboard with drinks fridge below Deck Saloon: • Located centrally with passageways to access forward and aft living spaces • Swept staircase providing direct access to aft deck area • Large U-shaped settee wrapping around saloon table to port • Saloon table, height adjustable • Double bench settee outboard to starboard • Counter tops forward and aft of seating to port and starboard • Sony TV mounted on aft end of deck house centrally • Storage drawers and lockers beneath seating units Galley: • Access from aft end of deck saloon via steps. • Countertop running along inboard side forward with washer drier contained in space beneath aft • Built-in fridge freezer aft of inboard countrertop • Worktop wrapping around outboard side of galley with built-in hob and oven aft. • Range of storage drawers and lockers beneath worktops throughout galley • Selection of storge lockers above galley worktops. • Microwave built-in to above galley storage unit forward Master Aft Cabin: • Accessed through galley aft. • Centrally located island double berth with walk-around access to port and starboard sides • Single seat outboard to starboard with dresser unit outboard • Large storage locker aft of dresser unit • Full-length mirror • Counter top outboard to port with storage locker forward and above countertop aft • Selection of drawers beneath countertop • Bookshelf spanning bunk overhead aft • Access to en-suite heads forward to port En-Suite Aft Heads: • Accessed from the forward port end of the aft cabin • Shower stall and mini-bath forward with fixed door screen • Electric flush marine toilet outboard centrally • Marble topped counter top aft with inset wash hand basin and mixer tap • Selection of lockers above and below countertops. DECK EQUIPMENT General: • Single stainless steel bow roller forward, anchor self-stowing in roller • Solid stainless steel guardrail running around deck edge with lower, plastic coated stainless steel guard wire. • Guard rail gates to port and starboard sides • Stainless steel fairleads to port and starboard forward • Stainless steel sampson posts fitted to deck, outboard to port and starboard • Toerail mounted midship cleats to port and starboard sides • Elevated aft decking area with fixed GRP moulded roof. • Full canvas sides (new August 2023) to screen off aft deck and create additional space • L-shaped seating unit to starboard with fixed table and moveable occasional seating • Bench seat unit to port • Storage locker space within seating unit bases • Flybridge accessible from deck forward to port, stainless steel ladder with teak treads • Access to transom bathing platform aft to port • Storage locker to starboard side of bathing platform • Deck shower at bathing platform • Fold out swimming ladder to port side of bathing platform • Dinghy storage chocks mounted centrally • Stainless steel fender baskets mount on rails around aft end of deck Canvas Work: • Flybridge cover • Flybridge bimini cover • Aft deck cover – removable panels fitting to sun cover, creating fully enclosed space (August 2023) • Selection of wheelhouse screen and window covers Anchoring & Mooring: • Bower Anchor – Trader 33KG stainless steel plough anchor on chain rode • Anchor Windlass – Maxwell electric windlass, chain gypsy and warping drum. Foot button controls on foredeck, secondary control switches at both helm stations • Passarelle – Almar stainless steel passarelle with teak gratings, electro hydraulic operation • Fenders – Selection • Mooring Warps - Selection Tender & Outboard: • Inflatable Dinghy – Lightweight Lodestar Inflatable dinghy with seat, oars, pump and storage bag • Outboard – Minn Kota Riptide RT40/SC/S 12VDC electric outboard with 12VDC battery SAFETY EQUIPMENT: General note on safety equipment: Any safety equipment such as liferafts, Epirbs, fire extinguishers and flares etc. are usually personal to the current owner(s) and if being left on-board as part of the sale of a used vessel may require routine servicing, replacement, or changing to meet a new owners specific needs. Navigation Lights: • Anchor light • Steaming Light • Port, starboard and stern navigation lights Life saving: • Horseshoe lifebuoy with light x2 • Liferaft – Requires service |
