This boat was designed and built by Reets Boatworks in Mayfield, NY. Although it may look similar to the Italian boat it is significantly different.
She is powered by twin Ilmor 6.2 V8’s along with a bow and stern thruster to make dockside maneuvering easy. The integrated swim platform makes for a nice all-around addition to the boat.
The boat is cold molded and 3 layers thick with west system epoxy between each layer. From the waterline down, it has carbon fiber in between each layer and a layer of Kevlar with fiberglass to protect the outside. That is then coated with Pettit Protect impervious bottom paint.
This boat has been used sparingly by the owner and has not been used in 2 summers.
The boat's design is a replica of the original boat frames and lines while using modern materials to improve strength, lower maintenance costs, and improve performance.
The bottom is 3 layers of ¼” Okoume plywood epoxy coated on all sides, bi-axial carbon fiber in-between the 1st, 2nd and 3rd layers. The bottom is wrapped with 6oz fiberglass and then faired using West system 410 microfibers.
The sides and the deck are composed of 3 layers. Two inner ¼” plywood skins will be coated on all surfaces and then planked with 3/8” Mahogany. The sides and deck were then stained traditional colors and varnished with 12-14 coats of Pettit flagship varnish.
All the screws and bolts used in the boat are stainless steel. All the epoxy used is the West System.
The bilge area is Coated with West system epoxy and then varnished with two coats.
Overview
Hardware:
- Taylor Made SS Windshield
- Lift rings, lift hardware, lift brackets
- Deck vents, rope chocks, motor cover hinge, rub rail, cutwater, bow light, stern light
- Drain plugs, shift linkage, steering wheel, steering linkages, Hydraulic Steering
- 2 Rudders, rudder stuffing box, driveshaft, shaft log, drive flange, Bronze prop
- Battery cables, dual batteries, all wiring, start switch lights
- Black ribbed Vinyl flooring, Fire extinguisher
- Bow and stern thrusters
- Wood Swim platform
Electronics:
- Simrad 9 with an audio unit
- Humminbird depth Gauge
Powertrain:
- The engines are Ilmor 6.2L 430hp.
- Direct drive stainless steel shafts.
- Freshwater cooling for saltwater.
- Twin aluminum 75 gallon tanks
- The gauges are replica gauges produced by classic instruments in their vintage Riva style.
