One of the key advancements of the MKII is the increased hull volume, allowing for a touch more luxury and convenience. However, the innovation doesn't stop at aesthetics - it is also presented in the revolutionized engineering behind the model. Embracing the cutting-edge technology, the entire platform now boasts full carbon construction for all full-width bulkheads as standard. To ensure optimal weight distribution and structural integrity, each component undergoes a meticulous vacuum infusion process.
The MKII introduces more versatility into this range with semi customizable layouts to suit most needs. The 3-cabin version features an intentionally open starboard aft cabin. This purposeful design allows for a multitude of possibilities, freeing up the space for owner customizations. The model features a stylish saloon, incorporating a large Corian and bamboo galley with ample storage. There is also a 4-zone induction cooktop paired with electric oven. A dual sink, microwave, storage for appliances and bar seating for 3 rounds off a fully functional kitchen with panoramic views to match. There is also generous seating arrangement in the saloon with rear bulkhead mounted popup 40inch television. The galley table can also be converted into a full-size queen bed, perfect for overflow guest accommodation, kids’ area or comfortable location for long voyage navigations. There are two large sunroofs on the saloon cabin for additional lighting with great visibility of the mast and sails.
The MKII version now comes standard with the powerful Torqeedo deep blue propulsion system, showcasing their dedication to embracing electric propulsion. The traditional diesel option is offered as an alternative choice. The optional 'sail by wire' package provides an enhanced sailing experience. This package elevates the already exceptional steering system to new heights by incorporating two additional outboard seated tiller steering. positions. The R series embraces the concept of blue water cruising, effortlessly covering vast distances without the need to overwork any of the components. Not only does this improve longevity, but also provides piece of mind whist consuming miles, day after day. The MKII is not just a vessel: it's a masterpiece that seamlessly merges offshore performance and modern living. Discover a world of possibilities with the MKII - a yacht that sets new standards in both form and function.
Electrical system
TORQEEDO DEEP BLUE 25KW 1400 RPM SHAFT DRIVE
ADVANCED SYSTEM MANAGEMENT (DC/DC, DC/AC)
CV 10 HOMOKINETIC JOINT SET
SUSPENSION KIT
DB CONVERTER COOLING KIT
DC/AC 6kW 1-phase
DC/DC HC-24V bidirectional
System Management Unit L Custom
System Management Unit S Custom
Fisher Panda 20KW DC Genset
Throttle twin top mounting
Hybrid System Management
BMW i3 chilled water cooled Battery 40kw
2x Power cable HV BMW 5 m
Shore Power Distribution L 1-ph
2x Power 24-3500 batteries
Router Deep Blue
1x 22kW Shore Charger
2x Thrust bearing B10-CV10-D30
Venting Kit
12 V Distribution box
2x 17-inch flexofold propellers
3.6 KW Solar Array
Electronics
B&G Triton
12-inch Multifunction interior saloon
4.1-inch multifunction interior Saloon
1 x 4.1-inch Multifunction, Mast mounted, FWD cockpit
1 x 4.1-inch pilot control mast, Mast mounted, FWD cockpit
Radar
AIS
VHF
Plumbing
Watermaker - Schenker ZEN100 Touch
Whale domestic double stack supply pumps with accumulator tanks
3x Showers with whale auto shower pumps
2x Whale manual bilge pumps
6x Whale electric hull bilge pumps
Washing machine (Compact)
1 x 40L hot water cylinders
Saloon
Veneer foam sandwich cabinetry with timber trims
Saloon table
Settee with upholstered cushions
Wear resistant timber vinyl flooring
LED overhead lighting
Stowage space under settee cushions
Front doorway access to foredeck
Airconditioning – Climma chiller unit with 4 x fancoil for bunks
TV Samsung 42" LED Smart TV, Full HD
2x Webasto coachroof sunroof with blinds (manual)
Galley
Veneer foam sandwich cabinetry with timber trims
Staron galley worktop surfaces
Single lever mixer faucet with pull out sprayer
Double s/s sink
Dish and cutlery drying recess with drainage
Vitrifrigo DW180 refrigerator/freezer (Dual Zone)
4 zone induction cook top
Convection oven
Separate garbage bin locker
Stowage space in shelf lockers
Microwave
4 x utility drawers
1 x Pot storage drawer
Cockpit
Flexiteek flooring throughout
Cockpit cushions
Cockpit Table
Hella Marine LED exterior lighting
Deck Hatches to steering compartments
Transom shower with mixer
2x Sugar scoop watertight utility lockers
Folding aft platform /davit with BBQ/ utility worktops and convertible lounge seat
Deck/Hull fittings
Composite lifeline Stanchions
1000w vertical windlass 10mm gypsy c/w handheld remote
Primary anchor / Rocna or similar
Secondary Anchor / fortress FX
Chain locker
100m anchor chain
2x Foredeck lockers
Sliding companionway door
Toughened Glass saloon Windows
Acrylic Hull Windows
2x Bow lockers
2x SZ10 Lewmar flush mounted hatches
4x SZ44 Lewmar flush mounted hatches
2x Goiot Escape hatches
6x Lewmar Size 1 mitre portlights
Goiot fwd cockpit door
Goiot pivoting helm window
6x DH5 Fenders with covers
6x Pop up mooring cleats
6+6 Mooring lines and fenders
Sailing configuration
Sparcraft aluminium spar package
Mast 19.4m (63.6ft)
Longeron
Cross Beams
Anchor box
Dyform seagull striker
Dyform standing rigging
Karver and spinlock clutch package
Dyneema running rigging
Antal Line driver for main sheet traveller control
Profurl C480 reefable furler (other options available)
2 x Harken 50 self-tailing rewind winches
2x Lewmar CW800 Captive reel winch for mainsheet
Antal full batten Fiberball system
Antal deck gear - Various
Mainsail - Ullman FiberPath (50% carbon / 50% twaron) – 91 sqm(979 sqft)
Self-tacking Jib - Ullman FibrePath (50% Carbon / 50% twaron) - 42m2 (452 sqft)
Storm Jib – Ullman Crosscut Dacron – 13 sqm (139.9sqft)
Code 0 – Ullman Red line Racing (Radial laminate) - 100sqm (1076 sqft)
Asymmetrical spinnaker - Blue line Cruising (Radial nylon) – 179sqm (1926sqft)
Rudder & Steering System (JEFA)
2x GRP Rudders
2x AIS630 Rudder stocks
2x Self-adjusting bearings with GRP tubes
Transmission steering system
Carbon Wheel
Integrated Autopilot drive
Safety Equipment
Viking life raft - 8UKL/ISO NON SOLAS "USA E" S.6M -3901 W
4x Pyrotechnics, Comet hand flare, red
4x Pyrotechnics, Comet parachute signal
Pyrotechnics, smoke signal, orange
TORCH
5x FLAGS C, N, W, Q, V
2x LIFEBOUY RING HORSESHOE
Lifebuoy light
RADAR REFLECTOR
CAPSIZE CONTAINER
FOG HORN
DANBUOY
8x life Jacket
4x Fire extinguishers
Disclaimer
The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change or withdrawal without notice.
