| HULL AND DECK • CE certified for Category A (unlimited ocean voyages) • Isophthalic NG gelcoats used to ensure bright and lasting finish • Polyester resins used throughout. Each batch of resin and gelcoat receives laboratory testing before use • Finite element analysis was performed in high-load areas during the engineering process. All aspects of design and construction are certified by the Bureau Veritas • White gelcoat topsides • Vacuum infused hull with discontinuous, end-grain balsa. Solid laminate in keel area. Barrier coat used to guard against osmosis • 3rd Generation counter-moulded structure glued and laminated to hull for strength. High-load zones cut-out for access to the hull. Subflooring in saloon area framed with aluminium • Hull ports in acrylic, bonded from exterior • Flared bowthruster tube moulded to hull to reduce drag • Composite bulkheads are vacuum infused and full laminated 360 degrees • Cove stripe indentation moulded into hull along with arrow at bow • Bilge areas finished with a gelcoat paint • The deck is vacuum infused with discontinuous, end-grain balsa. Wood coring used in high-load areas • Proprietary and highly-effective nonskid pattern is moulded into exposed deck areas and coachroof • Teak laid side decks, cockpit seating and sole • Sport transom with garage and opening swim platform • Electric air pump in tender garage • Stainless pulpit and pushpit • Mid ship gates • Bow stern and mid ship cleats • GS Composites 260 Carbon Passarelle • Epoxy encapsulated cast-iron keel • 3.15m draft keel option • Fully balanced spade rudder with a foam core and GRP skin over a stainless steel stock RIG & SAILS • LED spreader lights at each spreader • Sparcraft keel-stepped aluminium mast with fractional rig – painted white • Park Avenue style boom – painted white • Triple spreader design • Harken ‘Switch’ battencar system • Discontinuous Dyform wire standing rigging • Dyneema running rigging • 24vDC electric Genoa furler • Mainsheet mounted on GRP cockpit arch • Self-tacking track for Genoa • Split backstay • Harken hydraulic vang • Spinnaker deck fittings • Rigging for Code 0 • 2x Harken 70.2 electric self-tailing primary winches • 2x Harken 60.2 electric ‘Rewind’ self-tailing control line winches at companionway • North Sails fully-battened tri-radial mainsail • North Sails tri-radial self-tacking furling genoa • Code 0 with continuous line furler COVERS, CUSHIONS & CANVAS • Lazy bag for mainsail in Sunbrella • Sprayhood in Sunbrella material • Sunbrella skirt for tender garage • Multi-part foldaway bimini with Sunbrella fabric – attaching to mainsheet arch • Cockpit cushions with backrests • Foredeck cushions MACHINERY • Volvo D4-180 180hp diesel engine • 4 cylinders, turbo-charged 160 HP common rail fuel injection with electronic engine management (EVC) • Hydraulic gearbox with 2:48 ratio • Single lever engine throttle/shifter • ECI Volo/Raymarine interface or displaying engine readings on plotter screen • Sound insulation • GRP engine bed and liner • Dripless shaft gland with water lubrication • Stainless steel shaft 40mm with bronze strut • Stainless steel exhaust mixer with stainless steel exhaust fitting on hull • Extractor fan located in engine room for maximum sound deadening plus ventilation ducting • Engine hours: 1,871 as of Autumn 2022 • Engine last serviced – Autumn 2022 NAVIGATION AND ELECTRONICS • Steering system uses stainless steel cables driven by sprockets in the steering consoles • Jefa auto-aligning bearings • Twin composite helm pedestals with black composite steering wheels, steering compasses, stainless steel handrails • Emergency steering • 24vDC tunnel bowthruster • 4-bladed propeller ANCHORING & MOORING • 3,000w 24vDC reversing anchor windlass controllable from cockpit or foredeck • Chain counter • Stainless steel anchor with 100m of 14mm galvanised chain • Nomen folding mooring cleats • Fore and aft mooring lines • Fenders • Electric washdown pump in anchor locker ELECTRICAL SYSTEMS • 3 electrical systems: 24V for house systems, 12V for engine systems and 220V shore power and generator systems • 1x 50Ah 12vDC Dryfit gel start battery for engine • 1x 50Ah 12vDC start battery for generator • Emergency switchover from engine to generator start battery • 24vDC battery banks for bow and stern thrusters • 8x 210Ah 12vDC Dryfit gel service batteries joined in parallel and series to create 24vDC supply • Further batteries for bow thruster operation • 1x 115Amp 12vDC engine-mounted alternator for start batteries • 1x 110Amp 24vDC secondary alternator for service batteries • 25 Amp 12vDC battery charger for start batteries • 100 Amp 24vDC battery chargers for service batteries • Onan 17.5kw 220v AC 1,500rpm diesel generator • Generator hours: approx. 3,562 as of Autumn 2022 • Generator last serviced – Autumn 2022 • Mastervolt 2000Va 50Hz 220vAC inverter • 220vAC shore power with 2x connections • Various 12v, 24v and 220v power sockets throughout interior PLUMBING & GAS SYSTEMS • High-pressure twin 24vDC pumps with inline filter and accumulator tank • 80L hot water heater connected to engine heat exchanger and 220V electrical system • Hot & cold water shower at transom • Shore water connection in cockpit • Sea Recovery Aqua Matic 285 litre per hour watermaker 220v • Electric bilge pump located in bilge sump area with activation via switch at electrical panel • Dual-action manual bilge pump located in the cockpit • Electric bilge pump located in forward sail locker • Pressurised deck wash TANKAGE Fuel: • Total capacity of 825 litres • 500 litre stainless steel tank with pick-up and return fittings located under main salon sole • Secondary 325 litre roto moulded tank with transfer pump to primary tank • Inline fuel/water separator with electronic sensor for water • Fuel gauge at electrical panel Fresh Water: • Total capacity of 1,000 litres • 3x roto moulded tanks with separate fills and vents (2x 400 litre plus 1x 200 litre) • Tank manifold with selector valves located under saloon floor • Tank gauges located at the electrical panel Holding Tanks: • 3x 88 litre roto moulded holding tanks for with level gauges integrated to 3.5” display panel at companionway NAVIGATION & COMMUNICATION • Raymarine Axiom 12 multi-function touch screen chart plotter display • Raymarine Quantum radar scanner • Raymarine i70 multifunction display at port helm • Smart Transducer mounted in hull provides depth, speed and water temperature to system • Wind transducer for masthead • Raymarine autopilot control at starboard helm with computer and integrated gyro compass • Hydraulic autopilot arm connected directly to steering quadrant • Raymarine Class-B AIS transponder • Steering compasses on helm pedestals • Raymarine Ray260 dual station VHF with DSC DOMESTIC EQUIPMENT Galley: • Large galley to port of entryway with corian® countertop. • Stainless steel sink with cover Chrome mixer tap with spray nozzle • Foot pump with separate spout, pumps fresh water • Dish drying compartment with cover and drain • Soft-close, fully extending drawers with sliders and dampers that close the drawer slowly, silently and softly • Sliding waste bin under sink • Upper storage cabinets storage cabinets along hull with sliding doors. Tall pantry cabinet with shelves • Food preparation area next to the companionway with corian® countertop, drawers for storage and an upper cabinet • Large storage drawer under galley cooker • Stainless steel handrail in front of stove for protection • Galley return with integrated, leather-lined tray and bar cabinet • 1 large, fixed hull port with aviation shade. Opening flush hatch provides ventilation and includes pleated shade and insect screen • Courtesy lighting under steps • Gas stove with 3 burners and oven • Exhaust fan above cooker with light, vented to exterior • Single stainless steel sink with hot & cold fresh water supply + drain • Miele Speed Oven Combi convection oven/combination microwave • 360L combination fridge/freezer 24V. Fridge compartment with front opening, stainless steel door • 2 stainless steel freezer drawers are located in the lower part of the unit • 220vAC wine/drinks fridge in galley • Miele 220vAC dishwasher • Manual freshwater supplies to galley Laundry: • Miele 220vAC combined washing machine / dryer Heads: • 24vDC electric marine heads • Shower in each heads • Transom shower Heating & Ventilation: • Cruiseair 220vAC multi-zone air conditioning throughout with 60,000 BTU and reverse cycle for heating • Individual thermostat controls for each zone • Air conditioning air handler and thermostat for skipper cabin • Cabin fans throughout • Opening deck head hatches throughout Entertainment: • Fusion multi-media system with Bose speaker system plus cockpit speakers ACCOMMODATION • 5 cabins, 4 heads layout with master cabin aft • Crew cabin forward with head • Port & Starboard Guest Cabins with Double Berths • VIP Stateroom- Starboard Aft with Double Berth • Port Aft Guest Cabin with Twin Berths • Alpi teak interior joinery • Oak laminate sole-boards • White leatherette upholstery • White vinyl headlining Crew Cabin: • Access door into forward sail locker/ crew cabin (starboard head compartment only) • 2 single over/under berths • Heads with Toilet, Sink, Shower • Storage compartments • Access ladder to deck hatch Forward Guest Cabins (Port & Starboard): • Symmetrical to port and starboard • Double berth (203 cm x 130 cm / 6’7” x 51”) • Hanging locker with interior courtesy lighting and 3 storage drawers in lower unit • LED reading lights pneumatically-assisted opening storage cabinets under side deck • Indirect lighting under upper storage cabinets • 2 large storage compartments under berth • 2 opening deck hatches for light and ventilation with pleated shade and insect screen • Fixed hull port with aviation shade Forward Guest Heads (Port & Starboard): • Symmetrical to port and starboard • Cabinet with solid teak sink and corian® countertop • Lacquered upper storage lockers • Large deck hatch provide light and ventilation with pleated shade and insect screen • LED overhead lighting and task lighting • Standing shower separated by a perspex door and corian® shower floor • Electric, fresh-water flush toilet • Mirror • Clothes hook • Towel bar Starboard Aft Guest Cabin / VIP Stateroom: • Double berth (205 cm x 160 cm / 6’8” x 5’2”) • Hanging locker with interior courtesy lighting and 3 storage drawers in lower unit • Night stand to starboard of berth with book shelf • LED reading lights • Indirect lighting under side decks to each side • Fixed hull port with aviation shade • Large, curved opening port into cockpit for ventilation and evacuation with pleated shade • Sofa area which can be an extra berth for a child or small adult Starboard Aft En-Suite Heads Compartments: • Cabinet with solid teak sink and Corian® countertop • Lacquered upper storage lockers • Forced air ventilation • LED overhead lighting and task lighting • Standing shower separated by a Perspex door and Corian® shower floor • Electric, fresh-water flush toilet • Mirror • Towel bar Port Aft Guest twin Cabin: • Twin berths (205 cm x 68 cm / 6’8” x 26”) • Hanging locker with interior courtesy lighting and 3 storage drawers in lower unit • Night stand between berths • LED reading lights • Indirect lighting under side decks to each side • Fixed hull port with aviation shade • 2nd companionway into cockpit for ventilation and evacuation Port Aft En-Suite Heads Compartments: • Cabinet with solid teak sink and Corian® countertop • Lacquered upper storage lockers • Forced air ventilation • LED overhead lighting and task lighting • Standing shower separated by a Perspex door and Corian® shower floor • Electric, fresh-water flush toilet • Mirror • Towel bar Main Saloon: • Comfortable seating arrangement to starboard for 8 with view of sea though hull ports • Large sofa to port • Lockers above seating hinged storage compartments under settee seating • Large saloon table • Pneumatically assisted hinged central floorboards provide access to water systems, bilge sump and generator compartment • 2x folding armchairs in saloon • Courtesy lighting under steps to forward cabin and galley, as well as other steps throughout the boat • Indirect and overhead lighting with dimmer switches • 2 large, fixed hull ports with aviation shades • 4 opening flush hatches in saloon with pleated shade and insect screen integrated into ceiling panels SAFETY EQUIPMENT Life saving: General note on safety equipment: Any safety equipment such as life-rafts, Epirbs, fire extinguishers and flares etc. are usually personal to the current owner(s) and if being left on-board as part of the sale of a used vessel may require routine servicing, replacement, or changing to meet a new owners specific needs. • The vessel is equipped with safety equipment in line with Malta Commercial code. Please contact us for a full list of safety equipment. |
